ASME SA203 Grade D alloy steel for pressure vessels
Product :ASME SA203 Grade D is a kind of Ni-alloy steel material used to fabric high temperature pressure vessels. ASME SA203 Grade D this property is based on it's Ni composition.SA203 Grade D is used in fabricators serving industry, especially in the oil, gas and chemical supply markets. ASME SA203 has five grades or levels--Grade A/B/D/E/F.
Key words:SA203 Grade D,ASME SA203 Grade D,SA203 Grade D alloy steel,ASME SA203 Grade D alloy steel for pressure vessels,SA203 Grade D Ni-alloy steel, SA203 Grade D Ni-alloy steel material for fabric high temperature pressure vessels.
ASTM A203 Grade D steel chemical composition (%):
|
Composition |
Type |
Thickness (mm) |
Grade D |
|
C ≤ |
Heat analyse |
≤50 |
0.17 |
|
50~100 |
0.20 |
||
|
Product analyse |
|||
|
＞100 |
|||
|
Mn ≤ |
Heat analyse |
≤50 |
- |
|
＞50 |
0.70 |
||
|
Product analyse |
≤50 |
0.80 |
|
|
＞50 |
0.78 |
||
|
P ≤ |
Heat analyse |
- |
0.88 |
|
S ≤ |
Product analyse |
- |
0.035 |
|
Si |
Heat analyse |
- |
0.035 |
|
Product analyse |
- |
0.15~0.40 |
|
|
Ni |
Heat analyse |
- |
0.13~0.45 |
|
Product analyse |
- |
3.25~3.75 |
ASTM A203 Grade D steel Mechanical Properties:
|
Grade |
Nominal Nickel |
Yield Strength, min, ksi [MPa] |
Tensile Strength, min, ksi [MPa] |
Elongation in 8 in. [200 mm], min, % |
Elongation in 2 in. [50 mm], min, % |
|
D |
3.50 |
37 [255] |
65-85 [450-585] |
19 |
23 |
JW steel keeps more than 10,000 tons hot rolled and cold rolled SA203 Grade D steel in stock each month. We can meet our customer’s any quantity request. Based on these stock source, our advantage industry spread into steel process like : cutting ( any size and any shape ) drilling, welding, milling, machining and steel structure.
Henan Join-Win Im/Ex Corp. Can supply different steel grades of ASME SA203 and ASTM A203 steel plates , like SA203/A203 Grade A, SA203/A203Grade D, SA203/A203 Grade D, SA203/A203 Grade E , SA203/A203 Grade F . If you need any grades of ASME SA203/ASTM A203 steel plates , please do not hesitate to contact us as following ways .
Related link :ASME SA203 A,ASME SA203 B,ASME SA203 E
