A533 Gr D Mn-Mo-Ni alloy steel plates

Product: A533 Gr D is a kind of Mn-Mo and Mn-Mo-Ni alloy steel plates material used to fabric high temperature pressure vessels. Just because A533 Gr D with the special Manganese , Molybdenum , and Manganese, Molybdenum, Nickel chemical composition, A533 Gr D has the right property to be used in high temperature pressure vessel.

Key words: A533 Gr D,ASTM A533 Gr D,A533 Gr D Mn-Mo-Ni alloy steel plates,A533 Gr D Mn-Mo and Mn-Mo-Ni alloy steel plates ,A533 Gr D Mn-Mo-Ni alloy steel plates for pressure vessel,A533 Gr D Quenching + Tempering steel material.

ASTM A533 Gr D steel chemical composition :

Grade	C≤	Mn		P ≤	S ≤	Si		Ni		Mo
Grade	C≤	Heat analyse	Product analyse	P ≤	S ≤	Heat analyse	Product analyse	Heat analyse	Product analyse	Heat analyse	Product analyse
A533 Gr D	0.25	1.15~1.50	1.07~1.62	0.035	0.035	0.15~0.40	0.13~0.45	0.20~0.40	0.17~0.43	0.45~0.60	0.41~0.64

A533 Gr D Mechanical properties:

Grade D	Yield strength	tensile strength	temperature	Elongation
Quenching and tempering	690～825	≥585	-196℃	≥0.38
Quenching and tempering	690～825	≥585	-170℃	≥0.38

A533 Gr D steel delivery condition can be hot rolled, Cold rolled ,AR/CR/N/TMCP/T/QT as the customer request

Shanghai Royal Industry keeps more than 10,000 tons hot rolled and cold rolled A533 Gr D steel in stock each month. We can meet our customer’s any quantity request. Based on these stock source, our advantage industry spread into steel process like : cutting ( any size and any shape ) drilling, welding, milling, machining and steel structure.

We also have a high quality logistics team who make sure the fast delivery time and shipment. Anyway, if you want to find hot rolled and cold rolled A533 Gr D steel supplier, hot rolled and cold rolled A533 Gr D steel manufacturer, hot rolled and cold rolled A533 Gr D steel exporter, please contact Shanghai Royal Industry's sales team. We will give you the hot rolled and cold rolled A533 Gr D competitive price, hot rolled and cold rolled A533 Gr D good quality and best service from us.

Related link :ASTM A533 Gr A,ASTM A533 Grade B, ASTM A533 Grade C,ASTM A533
