SG295 carbon steel for boilers and pressure vessels
JIS G3116 SG295 carbon steel for boilers and pressure vessels
JIS G3116 SG295 is a kind of steel for pressure vessels .The standard of G3116 SG295 is JIS G3116 .SG255, SG295, SG325, SG365 is used to fabricate low temperature pressure vessels like gas cylinder.
Standard: JIS G3116
Thickness :1.5mm -5mm
Width : 400mm-2000mm
Length :1000mm-18000mm
MOQ: 1 PC
Delivery time : Promptly ( Stock) or 10-40 days (Production)
Stock : Available
MTC: Available
Payment Term : T/T or L/C At sight .
JIS G3116 SG295 Equivalent grade :Material Number 1.0243
ASTM A414 Gr.F
EN10120 P265N
DIN 17155
JIS G 3116 SG295 steel chemical composition:
|
Grade |
Chemical composition(max) |
||||
|
C |
Si |
Mn |
P |
S |
|
|
SG295 |
0.20 |
0.35 |
1.00 |
0.040 |
0.040 |
JIS G3116 SG295 steel Mechanical Properties :
|
Grade |
Yield point or proof stress |
Tensile strength |
Elongation % min |
Tensile test piece |
Bend ability |
||
|
Bending |
Inside radius |
Test piece |
|||||
|
SG295 |
295 |
400 |
26 |
NO.5 in rolling direction |
180° |
Thickness x 1.0 |
No.3 in rolling direction |
JIS G3116 SG295 steel chief application:
JIS G3116 SG295 steel is widely used in petroleum, chemical industry, power station, boiler, etc, used to make the reactor, heat exchanger, separator, spherical tank, liquefied gas, nuclear reactor pressure vessel, boiler steam drum steam, liquefied petroleum, hydropower station, high pressure pipe, spiral case and other equipment and components.
