SPV315 Carbon Steel for pressure vessels
JIS G3115 SPV315 Carbon Steel for pressure vessels
JIS is the standard of G3115 SPV 315 .JIS G3115 series steel grades include SPV235, SPV315, SPV355, SPV410, SPV 450, SPV490 .The application of JIS G3115 SPV 315 is to fabricate the low temperature pressure vessels.
Standard: JIS G3115
Thickness : 1.5mm -280mm
Width : 1000mm-4000mm
Length :1000mm-18000mm
MOQ: 1 PC
Delivery time : Promptly ( Stock) or 10-40 days (Production)
Stock : Available
MTC: Available
Payment Term : T/T or L/C At sight .
JIS G 3115 SPV 315 steel equivalent grade:
|
Europe |
Germany |
Japan |
||
|
EN 10028-2 |
DIN 17135 |
DIN17165 |
DIN17102 |
JIS G 3103 |
|
P296 GH |
A St 45 |
17 Mn 4 |
St E 315 |
SB450 |
JIS G3115 SPV315 steel chemical composition( %) :
|
Grade |
C ≤ |
Si ≤ |
Mn ≤ |
P ≤ |
S ≤ |
|
SPV315 |
≤0.18 |
0.15~0.35 |
1.60 |
0.030 |
0.030 |
JIS G3115 SPV315 pressure vessel steel Heat treatment:
According to the performance and user needs, can be hot rolled steel plate, controlled rolling, normalizing, annealing, tempering, normalizing + tempering, quenched and tempered state delivery, etc
JIS G3115 SPV315 steel chief application:
JIS G3115 SPV315 medium temperature pressure vessel steel is widely used in petroleum, chemical industry, power station, boiler, etc, used to make the reactor, heat exchanger, separator, spherical tank, liquefied gas, nuclear reactor pressure vessel, boiler steam drum steam, liquefied petroleum, hydropower station, high pressure pipe, spiral case and other equipment and components.
