P460NH the steel plate used for pressure vessels

DIN EN10273 P460NH the steel plate used for pressure vessels

DIN EN10273 P460NH is a kind of hot rolled steel plate used for boilers and pressure vessels. P460NH grade are used above all for manufacturing boilers, pressure vessels and pipes transporting hot liquids.

Standard: DIN EN10273
Thickness :1.5 mm -300mm
Width :1000mm-4000mm
Length :1000mm-18000mm
MOQ: 1 PC
Delivery time : Promptly ( Stock) or 10-40 days (Production)
MTC: Available
Payment Term : T/T or L/C At sight .

DIN EN10273 P460NH chemical composition (%) :

Grade	C	Si ≤	Mn ≤	P ≤	S ≤	Cr ≤	Mo ≤	Ni ≤
P460NH	≤0.20	0.60	1.00~1.70	0.030	0.025	≤0.30	≤0.10	≤0.80

DIN EN10273 P460NH Mechanical Property :

Thickness	Yield	Tensilmie	Elongation
mm	Min Mpa	Mpa	Min %
≤ 16	460	570-720	17
16 -35	450
35 -50	440
50 -70	420
70 -100	400	540-710	16
100 -150	380	520-690	16

DIN EN10273 P460NH application :
DIN EN10273 P460NH pressure vessel steel is widely used in petroleum, chemical industry, power station, boiler, etc, used to make the reactor, heat exchanger, separator, liquefied gas, nuclear reactor pressure vessel and etc.
