ASME SA302 Gr D steel plate for Pressure Vessel Plates

ASME SA302 Gr D steel plate for Pressure Vessel Plates

Product: ASME SA302 Gr D steel plate grade specification covers molybdenum alloy, intended particularly of welded boilers and others pressure vessels steel plate in SA302 Gr A, SA302 Grade B , SA 302 Gr C and SA 302 Gr D.

Key words: SA302 Gr D,ASME SA302 Gr D,SA302 Gr D steel plate,ASME SA302 Gr D steel plate for pressure vessel plates.SA302 Gr D steel plate grade specification covers molybdenum alloy steel.

ASME SA302 Gr D steel Chemical Composition (% ):

Composition

Type

Thickness

(mm)

D

C ≤

Heat analyse

≤25

0.20



Product analyse

50~100

0.23



>100

0.25

Mn ≤

Heat analyse

-

1.15~1.50



Product analyse

-

1.07~1.62

P ≤

Heat analyse

-

0.035

S ≤

Product analyse

-

0.035

Si

Heat analyse

-

0.15~0.40



Product analyse

-

0.13~0.45

Mo

Heat analyse

-

0.45~0.60



Product analyse

-

0.41~0.64

Ni

Heat analyse

-

0.70~1.00



Product analyse

-

0.67~1.03

ASME SA302 Grade D steel Mechanical Properties:

Grade

Tensile strength

kis [MPa]

Yield strength

min, kis [MPa]

Elongation in 8 in. [200 mm], min, %

Elongation in 2 in. [50 mm], min, %

SA302 Grade D

80-100[550-690]

50 [345]

17

20

ASME SA302 Gr D steel chief application:
ASME SA302 Gr D pressure vessel steel plate is widely used in petroleum, chemical industry, power station, boiler, etc, used to make the reactor, heat exchanger, separator, spherical tank, liquefied gas, nuclear reactor pressure vessel, boiler steam drum steam, liquefied petroleum, hydro power station, high pressure pipe.

We also have a high quality logistics team who make sure the fast delivery time and shipment. Anyway, if you want to find hot rolled and cold rolled SA302 Gr D steel supplier, hot rolled and cold rolled SA302 Gr D steel manufacturer, hot rolled and cold rolled SA302 Gr D steel exporter, please contact Shanghai Royal Industry ’s Ales team. We will give you the hot rolled and cold rolled SA302 Gr D competitive price, hot rolled and cold rolledSA302 Gr D good quality and best service from us

Related link :SA302 Grade A, SA302 Grade B ,SA302 Gr C,ASME SA302
