ASTM A225 alloy steel plates for pressure vessels
ASTM A225 alloy steel plates for pressure vessels
ASTM A225 is a kind of Mn-V-Ni alloy steel material used to fabric high temperature pressure vessels. Obviously, ASTM A225 this property is based on it's Mn, V, Ni composition. ASTM A225 has two grades or levels-- Grade C and D .
Standard: ASTM A-225/A-225M
Steel Grade : A-225 Gr.C, A-225 Gr.D
Thickness :1.5mm -260mm
Width :1000mm-4000mm
Length :1000mm-18000mm
MOQ: 1 PC
Product type : Steel plate
Delivery time : Promptly ( Stock) or 10-40 days (Production)
Stock : Available
MTC: Available
Payment Term : T/T or L/C At sight .
ASTM A225 steel chemical composition :
|
Grade |
The Element Max (%) |
||||||
|
C |
Si |
Mn |
P |
S |
V |
Ni |
|
|
A225GrC |
0.25 |
0.13–0.45 |
1.72 |
0,035 |
0,035 |
0.11-0.20 |
0.37-0.73 |
|
A225GrD |
0.25 |
0.13–0.45 |
1.72 |
0,035 |
0,035 |
0.11-0.20 |
0.37-0.73 |
Carbon Equivalent: Ceq = 【C+Mn/6+(Cr+Mo+V)/5+(Ni+Cu)/15】%
ASTM A225 steel Mechanical Property :
|
Grade |
Thickness |
Yield |
Tensile |
Elongation |
|
A225GrC |
- |
Min Mpa |
Mpa |
Min % |
|
- |
725-930 |
485 |
20 |
|
|
A225GrD |
6-75 |
415 |
550-725 |
19 |
|
75-200 |
380 |
515-690 |
17 |
ASTM A225 Application :
ASTM A225 mainly used in Shipbuilding, car, bridge, pressure vessels and so on .
