SG365 carbon steel for boilers and pressure vessels
JIS G3116 SG365 carbon steel for boilers and pressure vessels
JIS G3116 SG365 is a kind of steel for pressure vessels .The standard of G3116 SG365 is JIS G3116 .SG255, SG295, SG325, SG365 is used to fabricate low temperature pressure vessels like gas cylinder.
Standard: JIS G3116
Thickness :1.5mm -5mm
Width : 400mm-2000mm
Length :1000mm-18000mm
MOQ: 1 PC
Delivery time : Promptly ( Stock) or 10-40 days (Production)
Stock : Available
MTC: Available
Payment Term : T/T or L/C At sight .
JIS G3116 SG365 steel chemical composition :
|
Grade |
C ≤ |
Si ≤ |
Mn |
P ≤ |
S ≤ |
|
SG365 |
≤0.20 |
0.35 |
≤1.50 |
0.040 |
0.040 |
JIS G3116 SG365 steel Mechanical properties :
|
Grade |
Yield point or proof stress N/mm2 (min) |
Tensile strength N/mm2 min |
Elongation % min |
Tensile test piece |
Bend ability |
||
|
Bending Angle |
Inside radius |
Test piece |
|||||
|
SG365 |
365 |
540 |
20 |
NO.5 in rolling direction |
180° |
Thickness x 1.0 Thickness x 1.5 |
No.3 in rolling direction |
JIS G3116 SG365 steel chief application:
JIS G3116 SG365 steel is widely used in petroleum, chemical industry, power station, boiler, etc, used to make the reactor, heat exchanger, separator, spherical tank, liquefied gas, nuclear reactor pressure vessel, boiler steam drum steam, liquefied petroleum, hydropower station, high pressure pipe, spiral case and other equipment and components.
