10CrMo9-10 Boiler and Pressure Vessel Steel Plate

10CrMo9-10 Boiler and Pressure Vessel Steel Plate

10CrMo9-10 Boiler and Pressure Vessel Steel Plate

10CrMo9-10 steel grade is one of grade in EN10273, which is non alloy and alloy steels with specified elevated temperature properties. 10CrMo9-10 grade are used above all for manufacturing boilers, pressure vessels and pipes transporting hot liquids.

Shanghai Royal Industry is specialized in supplying EN10273 steel plate in grade 10CrMo9-10. For more information of 10CrMo9-10 steel plates, please check them in following:

10CrMo9-10 steel plate Chemical composition :

10CrMo9-10 Chemical Composition

Grade

The Element Max (%)

C

Si

Mn

P

S

Al(min)

N

10CrMo9-10

0.08-0.14

0.50

0.4-0.80

0.020

0.010



0.012

Cr

Cu

Mo

Nb

Ni

Ti

V

2.0-2.50

0.30

0.90-1.10









Carbon Equivalent: Ceq = 【C+Mn/6+(Cr+Mo+V)/5+(Ni+Cu)/15】%

10CrMo9-10 steel plate Technology:
HIC Test | NACE MR0175 | Z15 | Z25 | Z35 | S1 | S2 | S3 | S4.1 S5 | S6 | S7 | S8 | S9| S11 | S12 | S14 | S17

10CrMo9-10 steel plate application:

Grade



10CrMo9-10 Mechanical Property

Thickness

Yield

Tensilmie

Elongation

Impact Energy(KV J) min

10CrMo9-10

mm

Min Mpa

Mpa

Min %

-20°

+20°

≤ 16

310

480-630

18

f

f

31

16<to ≤40

300

480-630

18

f

f

31

40< to ≤60

290

480-630

17

f

f

27

60< to ≤100

280

470-620

17

f

f

27

100< to ≤150

260

460-610

17

f

f

27

150<to ≤250

250

450-600

17

f

f

27

10CrMo9-10 pressure vessel steel is widely used in petroleum, chemical industry, power station, boiler, etc, used to make the reactor, heat exchanger, separator, liquefied gas, nuclear reactor pressure vessel and etc.
