P500QH the steel plate used for pressure vessels

P500QH the steel plate used for pressure vessels

DIN EN10273 P500QH the steel plate used for pressure vessels

DIN EN10273 P500QH is a kind of hot rolled steel plate used for boilers and pressure vessels. P500QH grade are used above all for manufacturing boilers, pressure vessels and pipes transporting hot liquids.

Standard: DIN EN10273
Thickness :1.5 mm -300mm
Width :1000mm-4000mm
Length :1000mm-18000mm
MOQ: 1 PC
Delivery time : Promptly ( Stock) or 10-40 days (Production)
MTC: Available
Payment Term : T/T or L/C At sight .

DIN EN10273 P500QH chemical composition (%) :

Grade

C

Si ≤

Mn ≤

P ≤

S ≤

Cr ≤

Mo ≤

Ni ≤

P500QH

≤0.18

0.60

≤ 1.70

0.025

0.015

≤1.00

≤0.70

≤1.50

DIN EN10273 P500QH Mechanical Property :

Thickness

Yield

Tensilmie

Elongation

mm

Min Mpa

Mpa

Min %

≤ 50

500

500-670

17

50-100

480

100 -150

440

590-770

DIN EN10273 P500QH application :
DIN EN10273 P500QH pressure vessel steel is widely used in petroleum, chemical industry, power station, boiler, etc, used to make the reactor, heat exchanger, separator, liquefied gas, nuclear reactor pressure vessel and etc.
