13CrMo4-5 steel plate for steel for high temperature and pressure vessels
13CrMo4-5 steel plate for steel for high temperature and pressure vessels
13CrMo4-5 steel plate description:
13CrMo4-5 steel grade is a kind of steel which with Cr., Mo.,Cr-Mo that mainly applied for high temperature and pressure vessels.The steel grade 13CrMo4-5 is according to EN 10273 standard which with the yield strength of 228MPa.
13CrMo4-5 steel plate chemical composition (%)
|
Grades |
C |
Mn |
S |
P |
Si |
Cr |
Ni |
Cu |
Mo |
Nb+V+Ti |
|
13CrMo4-5 |
0.05- 0.17 |
0.40- 0.65 |
0.035 max |
0.035 max |
0.50- 0.80 |
1.0- 1.5 |
- |
- |
0.45- 0.60 |
- |
13CrMo4-5 steel plate Mechanical properties:
|
Grade |
Permissible yield point ratio |
Yield Strength MPa(min) |
Tensile Strength MPa |
Elongation % (min) |
|
13CrMo4-5 |
- |
228 |
380-550 |
22 |
Shanghai Royal Industry is a professional EN 10273 13CrMo4-5 steel exporter and a steel Stockist in china. We keep more than 1000 tons EN 10028-2 13CrMo4-5 steel in stock every month. If you want to get the EN 10028-2 13CrMo4-5 steel price, please do not hesitate to contact us. Any need in EN 10028-2 13CrMo4-5 Chemical Composition and Mechanical Properties, please feel free to contact us by email or calling to us.
