SA204 steel plate > ASME > Views - ASME SA204 steel plate for pressure vessels

ASME SA204 steel plate for pressure vessels

ASME SA204 steel plate for pressure vessels

ASME SSA204 steel plate for pressure vessels

Standard : ASME SA204/SA204 M

Steel grade:SA204 Gr A, SA204 Gr B, SA204 Gr C

Equal material: AFNOR 36206 15CD 2.05

ASME SA204 main description:
ASME SA204 steel grade specification covers molybdenum alloy, intended particularly of welded boilers and others pressure vessels steel plate in SA204 Gr A, SA204 Gr B and A 204 Gr C.

ASME SA204 steel Chemical Composition (% ):

Grades

C
max

Mn
max

S
max

P
max

Si

SA204grA

0.18

0.90

0.035

0.035

0.15-0.40

SA204grB

0.20

0.90

0.035

0.035

0.15-0.40

SA204grC

0.23

0.90

0.035

0.035

0.15-0.40

ASME SA204 steel Mechanical Properties:

Grade

Tensile Strength
(Mpa)

Yield Strength
(Mpa)

Elongation in
100-150 mm(%)

Elongation in
16 mm(%)

Max Thickness
(mm)

SA204

440-590

220-275

19

24

250

Supplementary Technology: HIC Test | NACE MR0175 | Z15 | Z25 | Z35 | S1 | S2 | S3 | S4.1 S5 | S6 | S7 | S8 | S9| S11 | S12 | S14 | S17

ASME SA204 steel chief application:
SA204 pressure vessel steel is widely used in petroleum, chemical industry, power station, boiler, etc, used to make the reactor, heat exchanger, separator, spherical tank, liquefied gas, nuclear reactor pressure vessel, boiler steam drum steam, liquefied petroleum, hydropower station, high pressure pipe.
