JIS G3103 SB480M Carbon Steel for boilers and pressure vessels

JIS G3103 SB480M Specification :
JIS G3103 SB480M is a kind of steel for boiler using.SB410, SB450, SB480M, SB450M, S480M are steel different steel grades of JIS G3103. SB410, SB450, SB480M, SB450M, S480M application is to fabricate boilers. The buyer choose different size and steel grade based on the different type boilers. JIS G3103 SB480M is available.

JIS G3103 SB480M Product Attributes :
Standard: JIS G3103
Steel Grade : SB410, SB450, SB480, SB450M, SB480M
Dimension range : 5mm -500mm x 1000mm-4000mm x 1000mm-18000mm
MOQ: 1 PC
Delivery time : Promptly ( Stock) or 10-40 days (Production)
Stock : SB480M is Available
MTC: Available
Payment Term : T/T or L/C At sight .

JIS G SB480M chemical composition :

Grade

Thickness mm

C ≤

Si ≤

Mn ≤

P ≤

S ≤

Mo

S480M

≤25

>25~50

>50~100

>100

0.20

0.23

0.25

0.27

0.15~1.40

0.90

0.030

0.030

0.45~0.60

Note: Heat analysis : Cu, Ni ≤ 0.40; Cr ≤ 0.30; Mo ≤ 0.12; Nb ≤ 0.02; V,Ti ≤ 0.03
Product analysis : Cu, Ni ≤ 0.43; Cr ≤ 0.34; Mo ≤ 0.13; Nb ≤ 0.03; V,Ti ≤ 0.04

JIS G3103 SB480M Main Application :
JIS G3103 SB480M Used for petrol, chemical, power station, boiler industry, etc. Making reactor, heat exchanger, separator, spherical tank, oil or gas tank, pressure vessel for nuclear reaction, high pressure water pipe, spiral case, and so on.

JIS G3103 SB480M Tests :
HIC, SSC, SPWHT, Macrostructure, detection of defects, Hardness and DWTT test for pipelines steel plates are also available.
