P420ML2 steel plate for pressure vessels

P420ML2 steel plate for pressure vessels

P420ML2 steel plate for pressure vessels

P420ML2 steel plate is a kind of material for boiler and pressure vessel steel. P420ML2 steel plates is characterised by a minimum yield strength of 390-420 MPa and by good weldability,so P420ML2 steel is mainly used to for manufacturing boilers.

P420ML2 steel plate chemical composition:(%)

Grade

P420ML2 max %



P420ML2 max %

C

0.16

Mo

0.20

Si

0.50

Nb

00.05

Mn

1.70

Ni

0.50

P

0.020

TI

0.05

S

0.015

Vi

0.10

AL

0.020 min





N

0.020





P420ML2 steel mechanical property:

grade

statue

thickness

Yield strength

Tensile strength

Elongation

(mm)

MPa (min)

MPa

% (min)









P420ML2

Normalized

≤ 16

420

500-660

19

16> to ≤40

400

500-660

19

40> to ≤63

390

500-660

19

P420ML2 steel plate application:
P420ML2 boiler and pressure vessel steel plates are widely used in the industries of petroleum, chemistry, power station and boiler .They can also be used to make equipments and components of reactor, heat exchanger, spherical tank, oil gas tank, liquefied gas tank, nuclear reactor pressure shell, boiler drum, liquefied petroleum gas cylinder, high pressure water pipes of hydropower station.
