P355M Hot rolled fine grain steel for pressure vessels

BS EN10028-5 P355M Hot rolled fine grain steel for pressure vessels

BS EN10028-5 P355M series steel grades include : P355M, P355ML1, P355ML2, P420M, P420ML1, P420ML2, P460M, P460ML1, P460ML2. BS EN10028-5 series steel grade is a kind of hot rolled steel grades, which usually used to fabric high temperature pressure vessels. The production process way is TMCP.

Standard: BS EN10028-5
Thickness :5 mm -380mm
Width :1000mm-4000mm
Length :1000mm-18000mm
MOQ: 1 PC
Delivery time : Promptly ( Stock) or 10-40 days (Production)
Stock : Available
MTC: Available
Payment Term : T/T or L/C At sight .

BS EN10028-5 P355M chemical composition (%) :

Grade	Material No.	C ≤	Si ≤	Mn≤	P≤	S≤	Alt≤	N≤
P355M	1.8821	0.14	0.50	1.60	0.025	0.020	0.020	0.015

Note: Mo ≤ 0.20 ; Nb ≤ 0.05; Ni ≤ 0.50; Ti ≤ 0.05; V ≤ 0.10

BS EN10028-5 P355M steel Mechanical Property :

Thickness	Yield	Tensile	Elongation
mm	Min Mpa	Mpa	Min %
≤16	355	450-610	22
16 -40	355
40 -63	345
