ASME SA299 Carbon Steel for Pressure Vessel Plates
ASME SA299 Carbon Steel for Pressure Vessel Plates
ASME SA299 is a kind of carbon steel material, it's product type is steel plates. Based on SA299 higher C, Mn, and Si composition, ASME SA299 widely used to fabric pressure vessel.There are two steel grades in the standard ASME SA299 , and they are SA299 Gr.A, SA299 Gr.B .
Standard: ASME SA299/ SA299M
Steel Grade : SA-299 Gr.A, SA-299 Gr.B
Thickness :1.5mm -260mm
Width :1000mm-4000mm
Length :1000mm-18000mm
MOQ: 1 PC
Product type : Steel plate
Delivery time : Promptly ( Stock) or 10-40 days (Production)
Stock : Available
MTC: Available
Payment Term : T/T or L/C At sight .
ASME SA299 Test: UT test/impact test/PWHT /Z15 Z25 Z35 etc.
ASME SA299 chemical composition :
|
Grade |
The Element Max (%) |
|||||
|
C |
Si |
Mn |
P |
S |
Mo |
|
|
SA299 GR.A |
0.28-0.30 |
0.13-0.45 |
0.84 -1.62 |
0.035 |
0.035 |
- |
|
SA299 GR.B |
0.28-0.30 |
0.13-0.45 |
0.84 -1.62 |
0.035 |
0.035 |
- |
Carbon Equivalent: Ceq = 【C+Mn/6+(Cr+Mo+V)/5+(Ni+Cu)/15】%
ASME SA299 Mechanical Property :
|
Grade |
Thickness |
Yield |
Tensile |
Elongation |
|
SA299 GR.A |
mm |
Min Mpa |
Mpa |
Min % |
|
t≦50 |
275-290 |
515-655 |
19 |
|
|
50<t≦200 |
275-290 |
515-655 |
19 |
|
|
SA299 GR.B |
t≦50 |
310-325 |
550-690 |
19 |
|
50<t≦200 |
310-325 |
550-690 |
19 |
