ASME SA515 GR 70 steel plate
ASME SA515 GR 70 is a kind of steel plates material used to fabric middle or high temperature pressure vessels. ASME SA515 has three levels :SA515 Grade 415, SA515 Grade 450, SA515 Grade 485. SA515 GR 70 under the standard of ASME SA515/SA515M is for high temperature pressure vessels.
SA515 GR 70 steel plate with good impact resistance, low temperature deformation, good welding performance, good anti-fatigue performance, good anti-crack properties, micro-alloying, high purity.
Standard: ASME SA515/SA515M
Dimension range : 3mm -500mm * 1000mm-4000mm * 1000mm-18000mm
SA515 GR 70 steel plate/sheet Mechanical Properties :
|
Mechanical Properties |
||||||
|
Grade |
Thickness |
Yield |
Tensile Strength |
Elongation |
Charpy V Notch Impact Test |
|
|
Degree |
Min Value |
|||||
|
SA515Gr.70 |
mm |
Min Mpa |
Mpa |
Min % |
- |
J |
|
5≤t≤50 |
260 |
70-620 |
21 |
- |
||
|
50≤t≤200 |
260 |
70-620 |
17 |
|
||
|
Note: Impact energy for impact test is on longitudinal |
||||||
SA515 GR 70 Boiler steel plate Chemical Composition
|
Chemical Composition |
|||||||
|
Grade |
The Element Max (%) |
||||||
|
C |
Mn |
P |
S |
Si |
Cr |
Mo |
|
|
SA515Gr.70 |
0.30-0.35 |
1.30 |
0.035 |
0.035 |
0.13-0.45 |
- |
- |
|
Zr |
B |
V |
Ti |
Cu |
Ni |
|
|
|
- |
- |
- |
- |
- |
- |
|
|
Delivery Status : Rolling, normalizing
ASME SA515 GR 70 structural steel plate application :
SA515 GR 70 steel is widely used in petroleum, chemical, power station, boiler and other industries, for the production reactor, heat exchanger, separator, spherical tank, gas tank, liquefied gas tank, nuclear reactor pressure shell, boiler drum, liquefaction Oil gas cylinders, high-pressure water pipe hydropower station, water wheel and other equipment and components.
