ASME SA543 Grade C alloy steel plates for pressure vessels
SA543 Grade C in the standard ASME SA543/SA543M is a kind of Ni-Cr-Mo alloy steel plates material used to fabric high temperature pressure vessels. ASME SA543 Grade C have two grades or levels. They are : grade B and grade C. SA543 Grade C need to be done the (Quenching + Tempering ) heat-treatment to meet the property requirement in the standard ASME SA543/SA543M.
Key words:SA543 Grade C,ASME SA543 Grade C,SA543 Grade C alloy steel plates,SA543 Grade C Ni-Cr-Mo alloy steel,ASME SA543 Grade C alloy steel plates for pressure vessels for fabric high temperature pressure vessels.
ASME SA543 Grade C steel chemical composition : %
|
Composition |
Grade B |
Grade C |
|
|
C≤ |
Heat analyse |
0.20 |
0.18 |
|
Product analyse |
|||
|
Mn ≤ |
Heat analyse |
0.40 |
0.40 |
|
Product analyse |
|||
|
S ≤ P ≤ |
Heat analyse |
0.020 |
0.020 |
|
Product analyse |
|||
|
Si |
Heat analyse |
0.15~0.40 |
0.15~0.40 |
|
Product analyse |
0.13~0.45 |
0.13~0.45 |
|
|
Ni ≤ |
Heat analyse |
2.25~4.00 |
2.00~3.50 |
|
Product analyse |
2.18~4.07 |
1.93~3.57 |
|
|
Cr |
Heat analyse |
1.00~1.90 |
1.00~1.90 |
|
Product analyse |
0.94~1.96 |
0.94~1.96 |
|
|
Mo |
Heat analyse |
0.20~0.65 |
0.20~0.65 |
|
Product analyse |
0.16~0.69 |
0.16~0.69 |
|
|
V |
Heat analyse |
0.03 |
0.03 |
ASME SA543 Grade C Principal Design Features :
One of the most widely used precipitation hardening grades in the business. While soft and ductile in the solution annealed condition, it is capable of high properties with a single precipitation or aging treatment. Characterized by good corrosion resistance, high harness, toughness and strength.
We also have a high quality logistics team who make sure the fast delivery time and shipment. Anyway, if you want to find hot rolled and cold rolled SA543 Grade C steel supplier, hot rolled and cold rolled SA543 Grade C steel manufacturer, hot rolled and cold rolled SA543 Grade C steel exporter, please contact Shanghai Royal Industry’s sales team. We will give you the hot rolled and cold rolled SA543 Grade C competitive price, hot rolled and cold rolled SA543 Grade C good quality and best service from us.
