ASTM A515 GR 415(450/485) steel plates for pressure vessels
ASTMA515 GR 415(450/485) is a kind of steel plates material used to fabric middle or high temperature pressure vessels. ASTM A515 has three levels : A515 Grade 415, A515 Grade 450, A515 Grade 485. A515 GR 415(450/485) under the standard of ASTM A515/A515M is for high temperature pressure vessels.
Standard: ASTM A515/A515M
Steel Grade : A515 Gr.415, A515 Gr.450, A515 Gr. 485
Thickness :3mm -500mm
Width :1000mm-4000mm
Length :1000mm-18000mm
MOQ: 1 PC
Product type : Steel plate
Delivery time : Promptly ( Stock) or 10-40 days (Production)
Stock : Available
MTC: Available
Payment Term : T/T or L/C At sight .
ASTM A515 GR 415(450/485) steel mechanical property:
|
Grade |
|
|||
|
Thickness |
Yield |
Tensile |
Elongation |
|
|
A515 Grade 415 |
mm |
Min Mpa |
Mpa |
Min % |
|
200 |
220 |
415-550 |
21 |
|
|
50 |
25 |
|||
|
A515 Grade 450 |
200 |
240 |
450-585 |
19 |
|
50 |
23 |
|||
|
A515 Grade 485 |
200 |
260 |
485-620 |
17 |
|
50 |
21 |
|||
Shanghai Royal Industry is a professional steel plate for pressure vessels manufacture and supplier. We can supply steel plate for pressure vessels if you have any need of A515 GR 415(450/485) steel plates, please do not hesitate to contact us. We will do service for you at any time.
