Home > ASTM > ASTM A738 Grade A Hot Rolled Boiler Plate

ASTM A738 Grade A Hot Rolled Boiler Plate

ASTM A738 Grade A is a kind of C-Mn-Si steel plates material used to fabric middle or low temperature pressure vessels. Obviously, A738 is divided into three grades or levels :A738 Gr. A, A738 Gr. B, A738 Gr. C . In order to meet the property requirement of ASTM SA-738/SA-738M standard, this material must be done heat-treatment.

ASTM A738 Grade A steel equivalent material :

CN	JP	USA	GM
GB	JIS	ASTM	DIN
713	G3115		17155
			Materal No	Mark
16Mng	SPV315	A414 Gr.G/A455	1.0482	19Mn5

ASTM A738 Grade A steel chemical composition (%) :

Compostion			A738 Grade A
C ≤ ①			0.24
Mn	Heat analyse	Thickness ≤65mm	≤1.50
		Thickness＞65mm	≤1.60
	Product analyse	Thickness ≤65mm	≤1.62
		Thickness＞65mm	≤1.72
P ≤ ① S ≤ ①			0.035
Si	Heat analyse		0.15~0.50
	Product analyse		0.13~0.55
Cu ≤	Heat analyse		0.35
	Product analyse		0.38
Ni ≤	Heat analyse		0.50
	Product analyse		0.53
Cr ≤	Heat analyse		0.25
	Product analyse		0.29
Mo ≤	Heat analyse	Thickness ≤65mm	0.08
		Thickness＞65mm	0.08
	Product analyse	Thickness ≤65mm	0.09
		Thickness＞65mm	0.09
V ≤	Heat analyse		0.07 ②
	Product analyse		0.08 ②
Nb ≤	Heat analyse		0.04 ②
	Product analyse		0.05 ②
Nb+V ≤	Heat analyse		0.08 ②
	Product analyse		0.10 ②

① means be suitable for both heat analyse and product analyse

② After agreement,can add V and Nb

③ For Grade C, Nb is not the required composition.

ASTM A738 Grade A steel mechanical properties :

Grade

Tensile strength

Ksi , [Mpa ]

Yield strength

Ksi , [Mpa ]

Elongation

In 2 in.[50mm],min,%

Grade A

75-95

[515-655]

[310]

We also have a high quality logistics team who make sure the fast delivery time and shipment. Anyway, if you want to find hot rolled and cold rolled A 738 Grade A steel supplier, hot rolled and cold rolled A 738 Grade A steel manufacturer, hot rolled and cold rolled A 738 Grade A steel exporter, please contact JW steel’s sales team. We will give you the hot rolled and cold rolled A 738 Grade A competitive price, hot rolled and cold rolled A 738 Grade A good quality and best service from us.
