A514 Grade A structural steel plate
A514 Grade A is a high-strength quenched and tempered alloy steel plate under ASTM standard. A514 Grade A steel plate/sheet is mainly used for welding bridge and other structures with thickness less than or equal to 6in. (150mm). Quenched and tempered alloy structural steel plate.
Standard : ASTM A514/A514M
Dimension range : 5-600mm*1500-4200mm*5800-16000mm
Heat treatment of ASTM A514 Grade A steel sheet /plate maybe subjected to normalling,quench-hardening and tempering,or tempering as necessary .Further ,thermomechanical control,or appropriate heat treatment may be applied upon the purchase .
A514 Grade A steel plate/sheet Mechanical Properties :
|
Mechanical Properties |
||||||
|
Grade |
Thickness |
Yield |
Tensile Strength |
Elongation |
Charpy V Notch Impact Test |
|
|
Degree |
Min Value |
|||||
|
A514Gr.A |
mm |
Min Mpa |
Mpa |
Min % |
- |
J |
|
5≤t≤20 |
690 |
760-895 |
18 |
- |
||
|
20≤t≤65 |
690 |
760-895 |
18 |
|
||
|
65≤t≤150 |
620 |
690-895 |
18 |
|
||
|
Note: Impact energy for impact test is on longitudinal |
||||||
A514 Grade A pressure vessel steel Chemical Composition :
|
Chemical Composition |
|||||||
|
Grade |
The Element Max (%) |
||||||
|
C |
Si |
Mn |
P |
S |
Cr |
Mo |
|
|
A514Gr.A |
0.15-0.21 |
0.40-0.80 |
0.80-1.10 |
0.035 |
0.035 |
0.50-0.80 |
0.18-0.28 |
|
|
Zr |
B |
|
|
|
|
|
|
|
0.05-0.15 |
0.0025 |
|
|
|
|
|
Delivery Status : Hot Rolled,CR, Normalized, Quenched, Tempering, TMCP, Electroslag Remelting Technical.
ASTM A514 Grade A Boiler steel plate application :
A514 Grade A high strength low alloy steel plates are mainly made mechanical device and other structural elements and so on drilling machine, power shovel, electricity drive wheel counter- mine trolley, mineral product automobile, car loader.
