A517 Grade J Boiler steel plate
ASTM A517 Grade J in the standard A517/A517M is a kind of high tensile alloy steel plates material used to fabric high temperature pressure vessels. ASTM A517 have six grades or levels. They are : Grade A, Grade B, grade E, grade F, grade J , grade P. ASTM A517 Grade J need to be done the (Quenching + Tempering ) heat-treatment to meet the property requirement in the standard ASTM A517.
Standard: ASTM A517/A517M
Dimension range : 3mm -260mm * 1000mm-4000mm * 1000mm-18000mm
ASTM A517 Grade J steel chemical composition :
|
Composition |
C |
Mn |
P |
S |
Si |
Mo |
B |
|
|
A517 Grade J |
Min |
0.12 |
0.45 |
- |
- |
0.20 |
0.50 |
0.001 |
|
Max |
0.23 |
0.78 |
0.035 |
0.035 |
0.37 |
0.69 |
0.005 |
|
Delivery Status : Hot rolled, CR, Normalized, Quenched, Tempering, TMCP, Z15, Z25, Z35
ASTM A517 Grade J Mechanical Property :
|
Mechanical Property |
||||
|
Grade |
Thickness |
Yield |
Tensile |
Elongation |
|
mm |
Min Mpa |
Mpa |
Min % |
|
|
A517 Grade J |
6-65 |
690 |
795-930 |
16% |
|
65-150 |
620 |
725-930 |
14% |
|
ASTM A517 Grade J pressure vessel steel application :
A517 Grade J steel plate is high strength quenched and tempered steel plate, pressure vessel steel plate, shipbuilding plate, offshore drilling platform steel plate, arc plate, mining and various engineering construction drilling rig, shovel, electric wheel dump truck, mining vehicle, Excavators, loaders , Bulldozers, all kinds of cranes, coal mine hydraulic support, and other mechanical equipment and other structural parts.
