A562 steel plate
A562 in the standard A-562/A-562M is a kind of Ni alloy steel plates material used to fabric pressure vessels which for glass lining or spreading metal storey. A562 belongs to C-Mn-Ti material steel plates.
Standard: ASTM A-562/A-562M
Dimension range :3mm -260mm x 1000mm-4000mm x 1000mm-18000mm
ASTM A562 steel plate/sheet Mechanical Properties :
|
Mechanical Properties |
|||
|
Grade |
Tensile Strength |
Yield Strength |
Elongation in 2 in , 50 mm,min,(%) |
|
SA553 Type II |
100-120 |
85 |
20 |
ASTM A562 pressure vessel steel Chemical composition :
|
Chemical composition |
|||||||
|
Grade |
C |
Mn |
S |
P |
Si |
Cu |
Ti |
|
A562 |
0.12 |
1.20-1.30 |
0.035 |
0.040 |
0.15~0.50 |
0.15 |
- |
Delivery Status :
Hot forging/hot rolling + annealing/normalizing + tempering/quenching + tempering
ASTM A562 Q&T steel plate application :
A562 steel plate is mainly used in oil, chemical, power station, boiler and other industries, for the production reactor, heat exchanger, separator, spherical tank, oil and gas pipe, liquefied gas tank, nuclear reactor pressure shell, boiler drum, liquefied petroleum Gas cylinders, high-pressure water pipes, water turbines and other equipment and components.
