A832 Gr. 21V steel plate
ASTM A832 Gr. 21V covers the specific chromium-molybdenum-vanadium alloy steel plates intended primarily for the fabrication of welded pressure vessels.A832 is divided into three grades or levels : A832 Grade 21V, A832 Grade 22V, A832 Grade 23V.
ASTM A832 Gr. 21V covers the specific chromium-molybdenum-vanadium alloy steel plates intended primarily for the fabrication of welded pressure vessels. The steel shall be killed and shall conform to the fine grain size requirement. All plates shall undergo normalization and tempering. Heat and product analyses shall be conducted and the steel shall conform to the prescribed chemical composition in carbon, manganese, phosphorus, sulfur, silicon, chromium, molybdenum, vanadium, titanium, boron, and copper. Tension and notch toughness testing shall be performed on the material and shall meet the required mechanical properties such as tensile strength, yield strength, and elongation.
ASTM A832 Gr. 21V is a kind of Cr-Mo-V alloy steel plates material used to fabric pressure vessels. A832 is divided into three grades or levels : A832 Grade 21V, A832 Grade 22V, A832 Grade 23V.
Standard: ASTM A-832/A-832M
Dimension range : 3mm -500mm * 1000mm-4000mm * 1000mm-18000mm
A832 Gr. 21V steel plate/sheet Mechanical Properties :
|
Mechanical Properties |
||||||
|
Grade |
Thickness |
Yield |
Tensile Strength |
Elongation |
Charpy V Notch Impact Test |
|
|
Degree |
Min Value |
|||||
|
A832 Gr. 21V |
mm |
Min Mpa |
Mpa |
Min % |
- |
J |
|
5≤t≤50 |
275 |
450-585 |
23% |
- |
||
|
50≤t≤150 |
275 |
450-585 |
20% |
|
- |
|
|
Note: Impact energy for impact test is on longitudinal |
||||||
A832 Gr. 21V Boiler steel plate CAhemical composition :
|
Composition |
Type |
A832 Gr. 21V |
|
C |
Heat analyse |
0.10~0.15 |
|
Product analyse |
0.08~0.18 |
|
|
Mn |
Heat analyse |
0.30~0.60 |
|
Product analyse |
0.25~0.66 |
|
|
P ≤ |
Heat analyse |
0.025 |
|
Product analyse |
0.025 |
|
|
S ≤ |
Heat analyse |
0.025 |
|
Product analyse |
0.025 |
|
|
Si ≤ |
Heat analyse |
0.10 |
|
Product analyse |
0.13 |
|
|
Cr |
Heat analyse |
2.75~3.25 |
|
Product analyse |
2.63~3.37 |
|
|
Mo |
Heat analyse |
0.90~1.10 |
|
Product analyse |
0.85~1.15 |
|
|
V |
Heat analyse |
0.20~0.30 |
|
Product analyse |
0.18~0.33 |
|
|
Ti |
Heat analyse |
0.015~0.035 |
|
Product analyse |
0.005~0.045 |
|
|
B |
Heat analyse |
0.001~0.003 |
|
Product analyse |
- |
|
|
Cu ≤ |
Heat analyse |
- |
|
Product analyse |
- |
|
|
Ni ≤ |
Heat analyse |
- |
|
Product analyse |
- |
|
|
Nb ≤ |
Heat analyse |
- |
|
Product analyse |
- |
|
|
Ca ≤ |
Heat analyse |
- |
|
Product analyse |
- |
Delivery Status : Normalizing + tempering or tempering state
ASTM A832 Gr. 21V pressure vessel steel plate application :
A832 Gr. 21V steel plate is mainly used in petroleum, chemical industry, power station, boiler and other industries, for the production reactor, heat exchanger, separator, spherical tank, oil tank, liquefied gas tank, nuclear reactor pressure shell, boiler drum, liquefaction Oil cylinders, high-pressure water pipe hydropower station, turbine volute and other equipment and components.
