ASME SA-841/SA-841M TMCP steel plate for pressure vessels
Standard: ASME SA-841/SA-841M
Steel Grade : SA841
Dimension range :1.2mm -500mm x 1000mm-4000mm x 1000mm-18000mm
MOQ: 1 PC
Delivery time : Promptly ( Stock) or 10-40 days (Production)
Stock : Available
MTC: Available
Payment Term : T/T or L/C At sight .
Latest price:
Specification :
SA841 is a kind steel plates used to fabric multilayer pressure vessels. SA841 steel plate is produced by TMCP process.
SA841 steel chemical composition %:
|
Grade |
C ≤ |
Mn ① |
P ≤ |
S ≤ |
Si |
|
|
≤ 40mm |
〉40mm |
|||||
|
SA841 |
0.20 |
0.70~1.35 |
1.00~1.60 |
0.030 |
0.030 |
0.15~0.50 |
|
Al ≥ |
V ≤ |
Nb ≤ |
Mo ≤ |
Cr ≤ |
Ni ≤ |
Cu ≤ |
|
② |
0.06 |
0.03 |
0.08 |
0.25 |
0.25 |
0.35 |
① If the carbon equivalent of the heat analyse is not more than 0.47%, the Mn composition of the heat analyse can be more than 1.35%, but must less than 1.60%. In this case , the way of carbon equivalent is as the following : CE=C+Mn/6+(Cr+Mo+V)/5+(Ni+Cu)/15(%) . And if in this case, the Mn composition of the product analyse should be not more than 12% Mn composition of the heat analyse.
② 0.020% pure aluminium, or 0.015% acid aluminium
