SA353 Ni-alloy steel plates
ASME SA353 is a kind of Ni-alloy steel plates material. In order to meet the property of standard ASME SA353, SA353 steel must be done twice Normalizing + once Tempering. The Ni composition in SA353 is 9%. Just because of this 9% Ni composition, SA353 have the very good resistant property to the high temperature.
Standard : ASME SA353/SA353M
Dimension range : 1.5mm -260mm * 1000mm-4000mm * 1000mm-18000mm
ASME SA353 steel plate/sheet Mechanical Property :
|
Mechanical Property |
|||
|
Grade |
Thickness (mm) |
Yield Min Mpa |
Elongation Min % |
|
SA353 |
5 < t≦30 |
585-820 |
18 |
|
30 < t |
575-820 |
18 |
|
ASME SA353 Boiler steel plate Chemical composition (%) :
|
Chemical composition |
||||||
|
Grade |
C ≤ |
Mn ≤ |
P ≤
|
S ≤ |
Si |
Ni |
|
SA353 |
0.13 |
0.90 |
0.035 |
0.035 |
0.15~0.40 |
8.50~9.50 |
Delivery Status : Normalizing + tempering or tempering state
SA353 pressure vessel steel sheet/plate application :
ASME SA353 steel is widely used in petroleum, chemical, power station, boiler and other industries, for the manufacture of reactor, heat exchanger, separator, spherical tank, paint tank, Oil gas cylinders, high-pressure water pipe hydropower stations, water turbines and other equipment and components.
