ASME SA517/SA517M high tensile alloy steel plates for pressure vessels

ASME SA517/SA517M high tensile alloy steel plates for pressure vessels

ASME SA517/SA517M high tensile alloy steel plates for pressure vessels

ASME SA517 in the standard SA517/SA517M is a kind of high tensile alloy steel plates material used to fabric high temperature pressure vessels. ASME SA517 have six grades or levels. They are : grade A, grade B, grade E, grade F, grade J , grade P. ASME SA517 need to be done the (Quenching + Tempering ) heat-treatment to meet the property requirement in the standard ASME SA517.

Standard: ASME SA517/SA517M
Steel Grade : SA517 GR A, SA517 GR B, SA517 GR E, SA517 GR F, SA517 GR H, SA517 GR P, SA517 GR Q, SA517 GR S
Thickness:3mm -260mm
Width :1000mm-4000mm
Length :1000mm-18000mm
MOQ: 1 PC
Delivery time : 10-40 days (Production)
MTC: Available
Payment Term : T/T or L/C At sight .

ASME SA517 steel chemical composition :

Composition

Grade A

Grade B

Grade E

Grade F

Grade H

Grade P

Grade Q

Grade S

C

Min

0.15

0.15

0.12

0.10

0.10

0.12

0.10

0.10

Max

0.23

0.23

0.22

0.22

0.23

0.23

0.23

0.22

Mn

Min

0.80

0.70

0.40

0.60

0.87

0.45

0.87

1.02

Max

1.20

1.10

0.78

1.10

1.41

0.78

1.41

1.62

P

0.035

0.035

0.035

0.035

0.035

0.035

0.035

0.035

S

0.035

0.035

0.035

0.035

0.035

0.035

0.035

0.035

Si

Min

0.40

0.15

0.10

0.15

0.13

0.20

0.13

0.13

Max

0.86

0.37

0.45

0.37

0.37

0.37

0.37

0.45

Ni

Min

-

-

-

0.70

0.27

1.20

1.15

-

Max

-

-

-

1.03

0.73

1.55

1.55

-

Cr

Min

0.50

0.40

1.40

0.40

0.36

0.85

0.94

-

Max

0.84

0.69

2.06

0.69

0.69

1.26

1.56

-

Mo

Min

0.18

0.15

0.40

0.40

0.17

0.45

0.36

0.10

Max

0.31

0.28

0.64

0.64

0.33

0.64

0.64

0.38

V

Min

-

0.03

-

0.03

0.02

-

0.02

-

Max

-

0.09

-

0.09

0.09

-

0.09

-

B

Min

-

0.0005

0.001

0.0005

0.0005

0.001

-

-

Max

0.0025

0.005

0.005

0.006

-

0.005

-

-

Note : Grade S (%) Cb : 0.07 , Ti : 0.07

ASME SA517 Mechanical Property :

Grade

Thickness

Yield

Tensile

Elongation

mm

Min Mpa

Mpa

Min %

SA517 Grade A

6-65

690

795-930

16%

65-150

620

725-930

14%

SA517 Grade B

6-65

690

795-930

16%

65-150

620

725-930

14%

SA517 Grade E

6-65

690

795-930

16%

65-150

620

725-930

14%

SA517 Grade F

6-65

690

795-930

16%

65-150

620

725-930

14%

SA517 Grade H

6-65

690

795-930

16%

65-150

620

725-930

14%

SA517 Grade P

6-65

690

795-930

16%

65-150

620

725-930

14%

SA517 Grade Q

6-65

690

795-930

16%

65-150

620

725-930

14%

SA517 Grade S

6-65

690

795-930

16%

65-150

620

725-930

14%
