Home > ASME > ASME SA533 Q&T Mn-Mo and Mn-Mo-Ni alloy steel plates for pressure vessels

ASME SA533 Q&T Mn-Mo and Mn-Mo-Ni alloy steel plates for pressure vessels

ASME SA533 Q&T Mn-Mo and Mn-Mo-Ni alloy steel plates for pressure vessels

ASME SA533 Q&T Mn-Mo and Mn-Mo-Ni alloy steel plates for pressure vessels

ASME SA533 in the standard ASME SA533/SA533M is a kind of Mn-Mo and Mn-Mo-Ni alloy steel plates material used to fabric high temperature pressure vessels. Just because SA533 with the special Manganese , Molybdenum , and Manganese, Molybdenum, Nickel chemical composition, SA533 has the right property to be used in high temperature pressure vessel. SA533 is also a Quenching + Tempering steel material. SA533 have four types A/B/C/D.

Standard: ASME SA533/SA533M
Steel Grade : SA533 Gr A, SA533 Gr B, SA533 Gr C, SA533 Gr D
Dimension range :3mm -260mm x 1000mm-4000mm x 1000mm-18000mm
MOQ: 1 PC
Delivery time : 10-40 days (Production)
MTC: Available
Payment Term : T/T or L/C At sight .

ASME SA533 steel chemical composition(%) :

Composition

Grade A

Grade B

Grade C

Grade D

C ≤ ①



0.25

0.25

0.25

0.25

Mn

Heat analyse

1.15~1.50

1.15~1.50

1.15~1.50

1.15~1.50

Product analyse

1.07~1.62

1.07~1.62

1.07~1.62

1.07~1.62

P ≤ ①

0.035

0.035

0.035

0.035

S ≤ ①

0.035

0.035

0.035

0.035

Si

Heat analyse

0.15~0.40

0.15~0.40

0.15~0.40

0.15~0.40

Product analyse

0.13~0.45

0.13~0.45

0.13~0.45

0.13~0.45

Ni

Heat analyse

-

0.40~0.70

0.70~1.00

0.20~0.40

Product analyse

-

0.37~0.73

0.67~1.03

0.17~0.43

Mo

Heat analyse

0.45~0.60

0.45~0.60

0.45~0.60

0.45~0.60

Product analyse

0.41~0.64

0.41~0.64

0.41~0.64

0.41~0.64
