ASME SA537 Class 1 steel plate for pressure vessels

ASME SA537 Class 1 steel plate for pressure vessels

ASME SA537 Class 1 is a kind of steel plate used for pressure vessel plates, heat-treated, carbon-manganese-silicon steel.It is in the American standard ASME SA537 .And ASME SA537 Class 1 plates shall be normalized.There are three steel grades or levels in the standard ASME SA537 . And they are Class 1 ,Class 2,Class 3 .

Key words:SA537 Class 1,SA537 Class 1 steel plate,ASME SA537 Class 1 steel plate,ASME SA537 Class 1 steel plate for pressure vessels,SA537Class1carbon-manganese-silicon steel,American standard SA537 Class 1.ASME SA537 Class 1.

ASME SA537 Class 1 steel Chemical Composition :

Grade

The Element Max (%)

C

Mn

P

S

Si

Cu

Ni

Cr

Mo

SA537 class 1

0.24

0.92-1.72

0.035

0.035

0.13-0.55

0.38

0.28

0.29

0.09

Carbon Equivalent: Ceq = 【C+Mn/6+(Cr+Mo+V)/5+(Ni+Cu)/15】%

ASME SA537 Class 1 Mechanical Property :

Grade

Thickness

Yield

Tensile

Elongation

SA537 class 1

mm

Min Mpa

Mpa

Min %

-65

345

485-620

22

65-100

310

450-585

-

100-150

-

-

18

Shanghai Royal Industry keeps more than 10,000 tons hot rolled and cold rolled SA537 Class 1 steel in stock each month. We can meet our customer’s any quantity request. Based on these stock source, our advantage industry spread into steel process like : cutting ( any size and any shape ) drilling, welding, milling, machining and steel structure.

We also have a high quality logistics team who make sure the fast delivery time and shipment. Anyway, if you want to find hot rolled and cold rolled SA537 Class 1 steel supplier, hot rolled and cold rolled SA537 Class 1 steel manufacturer, hot rolled and cold rolled SA537 Class 1 steel exporter, please contact Shanghai Royal Industry’s sales team. We will give you the hot rolled and cold rolled SA537 Class 1 competitive price, hot rolled and cold rolled SA537 Class 1 good quality and best service from us.

Related link : ASME SA537 Class 2 , ASME SA537 Class 3,ASME SA537
