ASME SA542 Grade E alloy steel plates for pressure vessels

ASME SA542 Grade E alloy steel plates for pressure vessels

SA542 Grade E in the standard SA-542/SA-542M is a kind of Mo-V alloy steel plates material used to fabric high temperature pressure vessels. SA542 have Five grades or levels. They are : grade A, grade B, grade C, grade D, grade E . SA542 Grade E need to be done the (Quenching + Tempering ) heat-treatment to meet the property requirement in the standard ASME SA-542/SA-542M.

Key words:SA542Grade E,ASME SA 542Grade E,SA542 Grade E alloy steel plates,SA542 Grade E Mo-V alloy steel plates,ASME SA542 Grade E alloy steel plates for fabric high temperature pressure vessels.

ASME SA542 Grade E steel chemical composition :

Composition

Grade B

C

Heat analyse

0.10~0.15

Product analyse

0.06~0.18

Mn

Heat analyse

0.30~0.60

Product analyse

0.25~0.66

P ≤

Heat analyse

0.010

Product analyse

0.010

S ≤

Heat analyse

0.010

Product analyse

0.010

Si ≤

Heat analyse

0.15

Product analyse

0.15

Ni ≤

Heat analyse

0.25

Product analyse

0.28

Cr

Heat analyse

2.85-3.25

Product analyse

2.63-3.37

Mo

Heat analyse

0.90~1.10

Product analyse

0.85~1.15

B

Heat analyse

-

Product analyse

-

V

Heat analyse

0.20-0.30

Product analyse

0.18-0.33

Ti

Heat analyse

-

Product analyse

-

Ca②



0.005-0.0015



-

Cu≤

Heat analyse

0.25

Product analyse

0.28

Nb

Heat analyse

0.015-0.070

Product analyse

0.010-0.075

Note : ① In SA 542/SA 542M-82 standard and the earlier standard, the steel plates whose thickness ≤ 125mm, C must be ≤ 0.15%
② Ca can be replace by REM as the agreement with manufacturer and buyer, if like this, then the total amount of REM should be stated.

ASME SA542 Grade E steel mechanical properties :

ASMESA542GradeE

Class4

Class4a

Tensilestrengthksi(Mpa)

85-110(585-760)

85-110(585-760)

Yieldstrength,Min,ksi(Mpa)

55(380)

60(415)

Elongation2in(50mm),%,A

20

18

Shanghai Royal Industry is a professional ASME SA542 steel stockist and supplier. We can supply different product type of ASME SA542. If you have any need of ASME SA542 steel please do not hesitate to contact us .
