ASTM A553 Q&T Ni-alloy steel plates for pressure vessels

ASTM A553 Q&T Ni-alloy steel plates for pressure vessels

A553 in the standard A553/A553M is a kind of Ni alloy steel plates material used to fabric high temperature pressure vessels, the composition of Ni is 8% and 9%. A553 have two types . They are : type I and type II . A553 need to be done the (Quenching + Tempering ) heat-treatment to meet the property requirement in the standard ASTM A553/A553M.

Standard: ASTM A553/A553M
Steel Grade : A553 type I, A553 type II
Thickness :3mm -260mm
Width :1000mm-4000mm
Length :1000mm-18000mm
MOQ: 1 PC
Delivery time : 10-40 days (Production)
Stock : Unavailable
MTC: Available
Payment Term : T/T or L/C At sight .

ASTM A553 steel chemical composition (%):

ASTM A553 Delivery Condition:
Normalizing/Tempering/Annealing/Quenching/QT and so on. (According to the customer's request of chemical composition and  mechanical properties.)

ASTM A553/A553M Abstract :
This specification covers 8 and 9% nickel alloy steel plates for use in the water quenched and tempered condition intended for the fabrication of welded pressure vessels. The materials shall be available in two types, namely Type I and II, having different chemical compositions. The maximum thickness of plates is limited only by the capacity of the material to meet the specified mechanical property requirements. The material is susceptible to magnetization and the use of magnets in handling after heat treatment should be avoided if residual magnetism would be detrimental to subsequent fabrication or service. The steels shall be killed and shall conform to the fine austenitic grain size requirement specified. The plates shall be tempered and hardened by heat treatment. The specimens shall be subjected to tension and Charpy V-notch impact tests.

This abstract is a brief summary of the referenced standard. It is informational only and not an official part of the standard; the full text of the standard itself must be referred to for its use and application. ASTM does not give any warranty express or implied or make any representation that the contents of this abstract are accurate, complete or up to date.
