ASTM A-517/A-517M high tensile alloy steel plates for pressure vessels

ASTM A517 in the standard A517/A517M is a kind of high tensile alloy steel plates material used to fabric high temperature pressure vessels. ASTM A517 have six grades or levels. They are : grade A, grade B, grade E, grade F, grade J , grade P. ASTM A517 need to be done the (Quenching + Tempering ) heat-treatment to meet the property requirement in the standard ASTM A517.

Standard: ASTM A-517/A-517M
Steel Grade : A517 GR A, A517 GR B, A517 GR E, A517 GR F, A517 GR H, A517 GR P, A517 GR Q, A517 GR S
Thickness:3mm -260mm
Width :1000mm-4000mm
Length :1000mm-18000mm
MOQ: 1 PC
Delivery time : 10-40 days (Production)
MTC: Available
Payment Term : T/T or L/C At sight .

ASTM A517 steel chemical composition :

Composition			Grade A	Grade B	Grade E	Grade F	Grade H	Grade P	Grade Q	Grade S
C	Min		0.15	0.15	0.12	0.10	0.10	0.12	0.10	0.10
C	Max		0.23	0.23	0.22	0.22	0.23	0.23	0.23	0.22
Mn	Min		0.80	0.70	0.40	0.60	0.87	0.45	0.87	1.02
Mn	Max		1.20	1.10	0.78	1.10	1.41	0.78	1.41	1.62
P			0.035	0.035	0.035	0.035	0.035	0.035	0.035	0.035
S			0.035	0.035	0.035	0.035	0.035	0.035	0.035	0.035
Si	Min	0.40		0.15	0.10	0.15	0.13	0.20	0.13	0.13
Si	Max	0.86		0.37	0.45	0.37	0.37	0.37	0.37	0.45
Ni	Min	-		-	-	0.70	0.27	1.20	1.15	-
Ni	Max	-		-	-	1.03	0.73	1.55	1.55	-
Cr	Min	0.50		0.40	1.40	0.40	0.36	0.85	0.94	-
Cr	Max	0.84		0.69	2.06	0.69	0.69	1.26	1.56	-
Mo	Min	0.18		0.15	0.40	0.40	0.17	0.45	0.36	0.10
Mo	Max	0.31		0.28	0.64	0.64	0.33	0.64	0.64	0.38
V	Min	-		0.03	-	0.03	0.02	-	0.02	-
V	Max	-		0.09	-	0.09	0.09	-	0.09	-
B	Min	-		0.0005	0.001	0.0005	0.0005	0.001	-	-
B	Max	0.0025		0.005	0.005	0.006	-	0.005	-	-

Note : Grade S (%) Cb : 0.07 , Ti : 0.07

ASTM A517 Mechanical Property :

Grade	Thickness	Yield	Tensile	Elongation
Grade	mm	Min Mpa	Mpa	Min %
A517 Grade A	6-65	690	795-930	16%
A517 Grade A	65-150	620	725-930	14%
A517 Grade B	6-65	690	795-930	16%
A517 Grade B	65-150	620	725-930	14%
A517 Grade E	6-65	690	795-930	16%
A517 Grade E	65-150	620	725-930	14%
A517 Grade F	6-65	690	795-930	16%
A517 Grade F	65-150	620	725-930	14%
A517 Grade H	6-65	690	795-930	16%
A517 Grade H	65-150	620	725-930	14%
A517 Grade P	6-65	690	795-930	16%
A517 Grade P	65-150	620	725-930	14%
A517 Grade Q	6-65	690	795-930	16%
A517 Grade Q	65-150	620	725-930	14%
A517 Grade S	6-65	690	795-930	16%
A517 Grade S	65-150	620	725-930	14%
