ASTM A533 Grade C Q&T alloy steel plates for pressure vessels
Product: ASTM A533 Grade C in the standard ASTM A533/A533M.ASTM A533 Grade C is a kind of Mn-Mo and Mn-Mo-Ni alloy steel plates material used to fabric high temperature pressure vessels. Just because ASTM A533 Grade C with the special Manganese , Molybdenum , and Manganese, Molybdenum, Nickel chemical composition, ASTM A533 has the right property to be used in high temperature pressure vessel. ASTM A533 Grade C is also a Quenching + Tempering steel material. ASTM A533 have four types A/B/C/D.
Key words:A533 Grade C,ASTM A533 Grade C,A533 Grade C Q&T alloy steel plates,A533 Grade C Mn-Mo and Mn-Mo-Ni alloy steel plates,ASTMA533 Grade C Q&T alloy steel plates for pressure vessels.
ASTMA533 Grade C steel chemical composition(%) :
|
Composition |
Grade C |
|
|
C ≤ ① |
|
0.25 |
|
Mn |
Heat analyse |
1.15~1.50 |
|
Product analyse |
1.07~1.62 |
|
|
P ≤ ① |
0.035 |
|
|
S ≤ ① |
0.035 |
|
|
Si |
Heat analyse |
0.15~0.40 |
|
Product analyse |
0.13~0.45 |
|
|
Ni |
Heat analyse |
0.70~1.00 |
|
Product analyse |
0.67~1.03 |
|
|
Mo |
Heat analyse |
0.45~0.60 |
|
Product analyse |
0.41~0.64 |
|
Note : ① Be suitable for both heat analyse and product analyse.
ASTM A533 Grade C steel application :
ASTMA533 Grade C Has excellent low-temperature impact toughness and mechanical properties, is typically used for environment - 100 ~ 196 ℃ low temperature conditions .Of 9% Ni steel is widely used in cryogenic separation processing, liquefied gas storage areas, such as a large vacuum low temperature storage of liquefied natural gas (LNG).
We also have a high quality logistics team who make sure the fast delivery time and shipment. Anyway, if you want to find hot rolled and cold rolled A533 Grade C steel supplier, hot rolled and cold rolled A533 Grade C steel manufacturer, hot rolled and cold rolled A533 Grade C steel exporter, please contact Shanghai Royal Industry’s Ales team. We will give you the hot rolled and cold rolled A533 Grade C competitive price, hot rolled and cold rolled A533 Grade C good quality and best service from us.
