ASTM A537 steel plate for pressure vessels

ASTM A537 is a kind of steel plate used for pressure vessel plates, heat-treated, carbon-manganese-silicon steel.It is in the American standard ASTM A537 .And ASTM A537 Class 1 plates shall be normalized.There are three steel grades or levels in the standard ASTM A537 . And they are Class 1 ,Class 2,Class 3 .

Standard: ASTM A537/ A537M
Steel Grade : Class 1 ,Class 2,Class 3
Thickness :1.5mm -260mm
Width :1000mm-4000mm
Length :1000mm-18000mm
MOQ: 1 PC
Product type : Steel plate
Delivery time : Promptly ( Stock) or 10-40 days (Production)
Stock : Available
MTC: Available
Payment Term : T/T or L/C At sight .

ASTM A537 Chemical Composition :

Grade	The Element Max (%)
Grade	C	Mn	P	S	Si	Cu	Ni	Cr	Mo
A537 class 1	0.24	0.92-1.72	0.035	0.035	0.13-0.55	0.38	0.28	0.29	0.09
A537 class 2	0.24	0.92-1.72	0.035	0.035	0.13-0.55	0.38	0.28	0.29	0.09
A537 class 3	0.24	0.92-1.72	0.035	0.035	0.13-0.55	0.38	0.28	0.29	0.09

Carbon Equivalent: Ceq = 【C+Mn/6+(Cr+Mo+V)/5+(Ni+Cu)/15】%

ASTM A537 Mechanical Property :

Grade	Thickness	Yield	Tensile	Elongation
A537 class 1	mm	Min Mpa	Mpa	Min %
	-65	345	485-620	22
	65-100	310	450-585	-
	100-150	-	-	18
A537 class 2	-65	415	550-690	22
	65-100	380	515-655	20
	100-150	315	485-620	-
A537 class 3	-65	380	550-690	22
	65-100	345	515-655	20
	100-150	275	485-620	-
