Home > ASTM > ASTM A736/A736M low carbon alloy steel plates for pressure vessels

ASTM A736/A736M low carbon alloy steel plates for pressure vessels

ASTM A736 is a kind of low Carbon, age-hardening, Ni-Cu-Cr-Mo alloy steel plates material used to fabric pressure vessels. A736 is divided into two grades or levels : A736 Grade A and A736 Grade C .

Standard: ASTM A736/A736M
Steel Grade : A736 Grade A, A736 Grade C
Thickness :3mm -500mm
Width :1000mm-4000mm
Length :1000mm-18000mm
MOQ: 1 PC
Delivery time : 10-40 days (Production)
Stock : Unavailable
MTC: Available
Payment Term : T/T or L/C At sight .

ASTM A736 steel chemical composition:

Composition	Type	A736 Grade A	A736 Grade C
C ≤	Heat analyse	0.07	0.07
C ≤	Product analyse	0.09	0.09
Mn	Heat analyse	0.40~0.70	1.30~1.65
Mn	Product analyse	0.35~0.78	1.21~1.77
P ≤	Heat analyse	0.025	0.025
S ≤	Product analyse	0.025	0.025
Si ≤	Heat analyse	0.40	0.40
Si ≤	Product analyse	0.45	0.45
Cr	Heat analyse	0.60~0.90	-
Cr	Product analyse	0.56~0.94	-
Ni	Heat analyse	0.70~1.00	0.70~1.00
Ni	Product analyse	0.67~1.03	0.67~1.03
Mo	Heat analyse	0.15~0.25	0.15~0.25
Mo	Product analyse	0.12~0.28	0.12~0.28
Cu	Heat analyse	1.00~1.30	1.00~1.30
Cu	Product analyse	0.95~1.35	0.95~1.35
Nb ≥	Heat analyse	0.02	0.02
Nb ≥	Product analyse	0.01	0.01

ASTM A736 Abstract :
This specification ASTM A736 covers two grades of low-carbon age-hardening alloy steel plates for welded pressure vessels and piping components.The two grades are nickel copper Chromium molybdenum columbium and nickel-copper-manganese-molybdenum-columbium alloy steel.They are A736 Grade A and A736 Grade C The heat treatment procedure for class 1, 2, 3 plates are presented. The steel shall conform to the required chemical compositions. Mechanical property requirements of the steel plates that include tension test requirements and notch-toughness requirements are presented in details.

This abstract is a brief summary of the referenced standard. It is informational only and not an official part of the standard; the full text of the standard itself must be referred to for its use and application. ASTM does not give any warranty express or implied or make any representation that the contents of this abstract are accurate, complete or up to date.
