ASTM A737/A737M high strength low alloy steel plates for pressure vessels

ASTM A737 is a kind of high strength low alloy steel plates material used to fabric pressure vessels.ASTM A737 is divided into two grades or levels :A737 Grade B and A737 Grade C

Standard: ASTM A737/A737M
Steel Grade : A737 Grade B, A737 Grade C
Thickness :3mm -500mm
Width :1000mm-4000mm
Length :1000mm-18000mm
MOQ: 1 PC
Delivery time : 10-40 days (Production)
Stock : Unavailable
MTC: Available
Payment Term : T/T or L/C At sight

ASTM A737 steel chemical composition :

Composition	Type	A737 GradeB	SA736 Grade C
C ≤	Heat analyse	0.20	0.22
C ≤	Product analyse	0.22	0.24
Mn	Heat analyse	1.15~1.50	1.15~1.50
Mn	Product analyse	1.07~1.62	1.07~1.62
P ≤	Heat analyse Product analyse	0.035	0.035
S ≤	Heat analyse Product analyse	0.035	0.035
Si ≤	Heat analyse	1.15~1.50	1.15~1.50
Si ≤	Product analyse	1.15~1.55	1.15~1.55
V	Heat analyse	-	0.04~0.11
V	Product analyse	-	0.03~0.12
Nb ≤	Heat analyse	0.05	-
Nb ≤	Product analyse	0.05	-
N	Heat analyse	-	0.03
N	Product analyse	-	0.03

ASTM A737 Abstract :
This specification covers high-strength low-alloy steel plates for service in welded pressure vessels and piping components. This material is particularly intended for piping and pressure vessel applications where high strength and improved toughness are required. Two grades, designated B and C, are covered. The steel shall be killed and shall conform to the fine austenitic grain size requirements specified. The material shall be normalized by heating to a suitable temperature which produces an austenitic structure holding a sufficient time to attain uniform heat throughout the material, and cooling in air. The steel shall conform to the requirements as to chemical compositions specified. The material as represented by the tension test specimen shall conform to the requirements specified.

This abstract is a brief summary of the referenced standard. It is informational only and not an official part of the standard; the full text of the standard itself must be referred to for its use and application. ASTM does not give any warranty express or implied or make any representation that the contents of this abstract are accurate, complete or up to date.

ASTM A737 Scope :
1. This specification ASTM A737 covers high-strength low-alloy steel plates for service in welded pressure vessels and piping components.

2 .This material ASTM A737 is particularly intended for piping and pressure vessel applications where high strength and improved toughness are required.

3. Two grades, designated B and C, are covered by this specification. A737 Grade B provides a minimum yield strength of 50 ksi [345 MPa]. A737 Grade C provides a minimum yield strength of 60 ksi [415 MPa].

4 .The maximum thickness of plates is limited only by the capacity of the chemical composition and heat treatment to meet the specified mechanical property requirements.

5.Plates should not be shipped in the as-rolled condition only except by mutual agreement between the manufacturer and the purchaser.

6. The values stated in either inch-pound units or SI units are to be regarded separately as standard. Within the text, the SI units are shown in brackets. The values stated in each system are not exact equivalents; therefore, each system must be used independently of the other. Combining values from the two systems may result in nonconformance with the specification.
