SA204 steel plate > JIS > Views - SBV1A Mn-Mo and Mn-Mo-Ni Alloy Steel Plates for Boilers and Other Pressure Vessels

SBV1A Mn-Mo and Mn-Mo-Ni Alloy Steel Plates for Boilers and Other Pressure Vessels

SBV1A Mn-Mo and Mn-Mo-Ni Alloy Steel Plates for Boilers and Other Pressure Vessels

SBV1A Mn-Mo and Mn-Mo-Ni Alloy Steel Plates for Boilers and Other Pressure Vessels

Standard:JISG3119

SBV1A pressure vessel steel equal material :ASTM A302 Gr.A

SBV1A is a kind of boiler and pressure vessel with manganese manganese molybdenum steel and molybdenum nickel hot rolled steel.

SBV1A pressure vessel steel chemical composition:(%)

Grade

C

Mn

Si

Mo

Al

P

S

SBV1A

≤0.20

0.95-1.3

0.15-0.4

0.45-0..6

0.75



≤0.030

≤0.030

SBV1A pressure vessel steel mechanical property:

Grade

Tensile strength MPa

Yield strength MPa

elongation
%

SBV1A

520-660

-

≥15

SBV1A pressure vessel steel Heat treatment :
According to the performance and user needs, can be hot rolled steel plate, controlled rolling, normalizing, annealing, tempering, normalizing + tempering, quenched and tempered state delivery, etc

SBV1A steel chief application:
SBV1A medium temperature pressure vessel steel is widely used in petroleum, chemical industry, power station, boiler, etc, used to make the reactor, heat exchanger, separator, spherical tank, liquefied gas, nuclear reactor pressure vessel, boiler steam drum steam, liquefied petroleum, hydropower station, high pressure pipe, spiral case and other equipment and components.
