A516 Gr450 pressure vessel steel
A516 Gr.450 steel plate belongs to the middle and low temperature pressure vessel carbon steel plate, good impact resistance, small temperature deformation, good welding performance, good fatigue resistance, anti-layered crack performance.
Delivery Status : Hot rolling, controlled rolling, normalizing, annealing and tempering
Standard : ASTM A516
Dimension range : 5-600mm*1500-4200mm*5800-16000mm
ASTM A516 Gr450 Boiler steel plate Mechanical Properties :
|
Mechanical Properties |
||||||
|
Grade |
Thickness |
Yield |
Tensile Strength |
Elongation |
Charpy V Notch Impact Test |
|
|
Degree |
Min Value |
|||||
|
A516 Gr.450 |
mm |
Min Mpa |
Mpa |
Min % |
- |
J |
|
5≤t≤40 |
240 |
450-585 |
23% |
- |
||
|
40≤t≤100 |
240 |
450-585 |
19% |
|
|
|
|
Note: Impact energy for impact test is on longitudinal |
||||||
A516 Gr450 pressure vessel steel Application :
A516 Gr450 pressure vessel steel widely used in petroleum, chemical, power plants, boilers and other industries for the production of reactors, heat exchangers, separators, tank, no tank, gas cans, nuclear reactor pressure vessel, boiler drum, liquefied petroleum gas cylinders, high pressure water station, water wheels and other equipment and components volute.
