ASTM A516 Grade 450 Carbon Steel Plate

ASTM A516 Grade 450 Carbon Steel Plate

Product:This specification ASTM A516 Grade 450 covers carbon steel plates intended primarily for use in welded pressure vessels where improved notch toughness is important. ASTM A516 allows for four different strength levels. The most common is Grade 70.

Key words:A516 Grade 450,ASTM A516 Grade 450, A516 Grade 450 Carbon Steel Plate,ASTM A516 Grade 450 Carbon Steel Plate,ASTM A516 Grade 450 Carbon Steel Plate for pressure vessels.

ASTM A516 Grade 450 steel equivalent material:

Chinese

Japanese

American

Germany

GB 22g

JIS G3118

SGV450

ASTM A414

Grade E

DIN 1715

Material NO.1.0425

ASTM A516 Grade 450 steel chemical composition : %

Compostion

A516 Grade 450(450)

C ≤ ①

≤ 12.5mm

0.24

> 12.5mm ~ 50mm

0.26

> 50mm ~ 100mm

0.28

> 100mm ~ 200mm

0.29

> 200mm

0.29

Mn

≤12.5mm

Heat analyse

0.85~1.20

Product analyse

0.79~1.30

12.5mm~50mm

Heat analyse

0.85~1.20

Product analyse

0.79~1.30

P ≤ ①

0.035

S ≤ ①

0.035

Si

Heat analyse

0.15~0.40

Product analyse

0.13~0.45

① means be suitable for both heat analyse and product analyse

ASTM A516 Grade 60 Mechanical Properties :

Grade

Tensile KSI

Yield KSI Min

Elongation Min %

8&”

2&”

65

65-85

35

19

23

Shanghai Royal Industry is a professional ASTM A516 and ASTM A516 steel stockist and supplier. We can supply different product type and grades of ASTM A516 . If you have any need of ASTM A516 steel please do not hesitate to contact us .
