ASME SA515 Gr.70 steel plate
Product : ASME SA515 Gr.70 steel plate
ASME SA515Gr.70 steel plate is a kind of steel plates material used to fabric middle or high temperature pressure vessels. ASME SA-515/SA-515M: SA515 GR 60 (415), SA515 GR 65 (450), SA515 GR 70 (485) .
The standard is ASME SA515/SA515M. Here we talk about something about SA515 Gr.70. Thickness :3mm -500mm
Width :1000mm-4000mm
Length :1000mm-18000mm
MOQ: 1 PC
Product type : Steel plate
Delivery time : Promptly ( Stock) or 10-40 days (Production)
Stock : Available
MTC: Available
Payment Term : T/T or L/C At sight .
SA 515 grade 70 Chemical Chemical Composition:
|
Grade |
The Element Max(%) |
||||
|
C |
Mn |
P |
S |
Si |
|
|
SA515 grade 70 |
0.24-0.33 |
1.30 |
0.035 |
0.035 |
0.13-0.45 |
SA 515 grade70 Mechnical Property:
|
Grade |
Thickness |
Yield |
Tensile |
Elongation |
|
mm |
Min Mpa |
Mpa |
Min % |
|
|
SA515 grade70 |
200 |
260 |
485-620 |
17 |
|
50 |
21 |
Shanghai Royal Industry is a professional steel plate manufacture and supplier. Our products are enough to meet the buyers’ ex-stock requirement. Please feel free to contact us if you are interested in any of our products. We sincerely hope to cooperate with clients from all over the world.
