ASME SA-515/SA-515M steel plates for pressure vessels

ASME SA-515/SA-515M steel plate

Standard: ASME SA-515/SA-515M
Steel Grade : SA515 Gr.60, SA515 Gr.65, SA515 Gr. 70
Dimension range :3mm -500mm x 1000mm-4000mm x 1000mm-18000mm
MOQ: 1 PC
Product type : Steel plate
Delivery time : Promptly ( Stock) or 10-40 days (Production)
Stock : Available
MTC: Available
Payment Term : T/T or L/C At sight .
Latest price:

Specification :
SA515 is a kind of steel plates material used to fabric middle or high temperature pressure vessels. Obviously, ASME SA-515/SA-515M SA515 is divided into three levels : SA515 GR 60 (415), SA515 GR 65 (450), SA515 GR 70 (485)

SA515 steel chemical composition :%

Composition		Grade 60(415)	Grade 65(450)	Grade 70(485)
C ≤	≤25 ＞25~50 ＞50~100 ＞100~200 ＞200	0.24	0.28	0.31
		0.27	0.31	0.33
		0.29	0.33	0.35
		0.31	0.33	0.35
		0.31	0.33	0.35
Mn ≤	Heat analyse	0.90	0.90	1.20
Mn ≤	Product analyse	0.98	0.98	1.30
P ≤		0.035	0.035	0.035
S ≤		0.035	0.035	0.035
Si	Heat analyse	0.15~0.40	0.15~0.40	0.15~0.40
Si	Product analyse	0.13~0.45	0.13~0.45	0.13~0.45

Note: C ,P, S chemical position data is suitable for both heat analyse and product analyse.
