ASME SA-542/SA-542M Q&T Mo-V alloy steel plates for pressure vessels

ASME SA-542/SA-542M

Standard: ASME SA-542/SA-542M
Steel Grade : SA542 GR A, SA542 GR B, SA542 GR C, SA542 GR C, SA542 GR E
Dimension range :3mm -260mm x 1000mm-4000mm x 1000mm-18000mm
MOQ: 1 PC
Delivery time : 10-40 days (Production)
Stock : Unvailable
MTC: Available
Payment Term : T/T or L/C At sight .
Latest price:

Specification :
SA542 in the standard SA-542/SA-542M is a kind of Mo-V alloy steel plates material used to fabric high temperature pressure vessels. SA542 have Five grades or levels. They are : grade A, grade B, grade C, grade D, grade E . SA542 need to be done the (Quenching + Tempering ) heat-treatment to meet the property requirement in the standard ASTM SA-542/SA-542M.

ASTM SA-542/SA-542M SA542 steel chemical composition :%

Composition		Grade A	Grade B	Grade C	Grade D	Grade E
C	Heat analyse	≤ 0.15	0.11~0.15	0.10~0.15	0.11~0.15	0.10~0.15
C	Product analyse	≤ 0.18 ①	0.09~0.18	0.08~0.18	0.09~0.18	0.06~0.18
Mn	Heat analyse	0.30~0.60	0.30~0.60	0.30~0.60	0.30~0.60	0.30~0.60
Mn	Product analyse	0.25~0.66	0.25~0.66	0.25~0.66	0.25~0.66	0.25~0.66
P ≤	Heat analyse	0.025	0.015	0.025	0.015	0.010
P ≤	Product analyse	0.025	0.015	0.025	0.020	0.010
S ≤	Heat analyse	0.025	0.015	0.025	0.010	0.010
S ≤	Product analyse	0.025	0.015	0.025	0.015	0.010
Si ≤	Heat analyse	0.50	0.50	0.13	0.010	0.15
Si ≤	Product analyse	0.50	0.50	0.13	0.013	0.15
Ni ≤	Heat analyse	0.40	0.25	0.25	0.25	0.25
Ni ≤	Product analyse	0.43	0.28	0.28	0.28	0.28
Cr	Heat analyse	2.00~2.50	2.00~2.50	2.75~3.25	2.00~2.50	2.75~3.25
Cr	Product analyse	1.88~2.62	1.88~2.62	2.63~3.37	1.08~2.62	2.63~3.37
Mo	Heat analyse	0.90~1.10	0.90~1.10	0.90~1.10	0.90~1.10	0.90~1.10
Mo	Product analyse	0.85~1.15	0.85~1.15	0.85~1.15	0.85~1.15	0.85~1.15
B	Heat analyse	-	-	0.001~0.003	0.0022	-
B	Product analyse	-	-	-	-	-
V	Heat analyse	≤ 0.03	≤ 0.02	0.20~0.30	0.25~0.354	0.20~0.30
V	Product analyse	≤ 0.04	≤ 0.03	0.18~0.33	0.23~0.37	0.18~0.33
Ti	Heat analyse	-	-	0.015~0.035	≤ 0.030	-
Ti	Product analyse	-	-	0.005~0.045	≤ 0.035	-
Ca②		-	-	-	≤ 0.015	0.005~0.0015
Ca②		-	-	-	≤ 0.020	-
Cu≤	Heat analyse	0.40	0.25	0.25	0.20	0.25
Cu≤	Product analyse	0.43	0.28	0.28	0.25	0.28
Nb	Heat analyse	-	-	-	≤ 0.07	0.015~0.070
Nb	Product analyse	-	-	-	≤ 0.08	0.010~0.075

Shanghai Royal Industry is a professional ASME SA542 steel stockist and supplier. We can supply different product type of ASME SA542. If you have any need of ASME SA542 steel please do not hesitate to contact us .
Related link :

ASME SA542 Grade A	Class1		Class2		Class3		Class4
ASME SA542 Grade B	Class1		Class2		Class3		Class4
ASME SA542 Grade C	Class1		Class2		Class3		Class4
ASME SA542 Grade D	Class1	Class2		Class3		Class4		Class4a
ASMESA542GradeE	-

Note : ① In A 542/A 542M-82 standard and the earlier standard, the steel plates whose thickness ≤ 125mm, C must be ≤ 0.15%
② Ca can be replace by REM as the agreement with manufacturer and buyer, if like this, then the total amount of REM should be stated.
