ASME SA-553/SA-553M Q&T 8% and 9% Ni-alloy steel plates for pressure vessels
Standard: ASME SA-553/SA-553M
Steel Grade : SA553 type I, SA553 type II
Dimension range :3mm -260mm x 1000mm-4000mm x 1000mm-18000mm
MOQ: 1 PC
Delivery time : 10-40 days (Production)
Stock : Unvailable
MTC: Available
Payment Term : T/T or L/C At sight .
Latest price:
Specification :
SA553 in the standard SA-553/SA-553M is a kind of Ni alloy steel plates material used to fabric high temperature pressure vessels, the composition of Ni is 8% and 9%. SA553 have two types . They are : type I and type II . SA553 need to be done the (Quenching + Tempering ) heat-treatment to meet the property requirement in the standard ASTM SA-553/SA-553M.
ASTM SA-553/SA-553M SA553 steel chemical composition :%
|
Composition |
|||
|
C≤ |
Heat analyse |
0.13 |
0.13 |
|
Product analyse |
|||
|
Mn ≤ |
Heat analyse |
0.90 |
0.90 |
|
Product analyse |
0.98 |
0.98 |
|
|
S ≤ P ≤ |
Heat analyse |
0.035 |
0.035 |
|
Product analyse |
|||
|
Si |
Heat analyse |
0.15~0.40 |
0.15~0.40 |
|
Product analyse |
0.13~0.45 |
0.13~0.45 |
|
|
Ni ≤ |
Heat analyse |
8.50~9.50 |
7.50~8.50 |
|
Product analyse |
8.40~9.60 |
7.40~8.60 |
|
