P420ML2 steel plate
P420ML2 steel plate is a kind of material for boiler and pressure vessel steel. P420ML2 steel plates is characterised by a minimum yield strength of 390-420 MPa and by good weldability,so P420ML2 steel is mainly used to for manufacturing boilers.
P420ML2 steel mechanical property:
|
grade |
statue |
thickness |
Yield strength |
Tensile strength |
Elongation |
|
(mm) |
MPa (min) |
MPa |
% (min) |
||
|
|
|
|
|
||
|
P420ML2 |
Normalized |
≤ 16 |
420 |
500-660 |
19 |
|
16> to ≤40 |
400 |
500-660 |
19 |
||
|
40> to ≤63 |
390 |
500-660 |
19 |
P420ML2 boiler and pressure vessel steel plates are widely used in the industries of petroleum, chemistry, power station and boiler .They can also be used to make equipments and components of reactor, heat exchanger, spherical tank, oil gas tank, liquefied gas tank, nuclear reactor pressure shell, boiler drum, liquefied petroleum gas cylinder, high pressure water pipes of hydropower station.
