ASME SA517 Grade F high tensile alloy steel plates

ASME SA517 Grade F in the standard SA517/SA517M is a kind of high tensile alloy steel plates material used to fabric high temperature pressure vessels. ASME SA517 have six grades or levels. They are : Grade A, Grade F, grade E, grade F, grade J , grade P. ASME SA517 Grade F need to be done the (Quenching + Tempering ) heat-treatment to meet the property requirement in the standard ASME SA517.

Key words:SA517 Grade F,ASME SA517 Grade F, SA517 Grade F Carbon Steel Plate,ASME SA517 Grade F Carbon Steel Plate,ASME SA517 Grade F Carbon Steel Plate for pressure vessels.

ASME SA517 Grade F steel chemical composition :

GradeF	C	Mn	P	S	Si	Cr	Mo	B	V	Ni
Min	0.10	0.60	-	-	0.15	0.40	0.40	0.0005	0.03	0.70
Max	0.22	1.10	0.035	0.035	0.37	0.69	0.64	0.006	0.09	1.03

ASME SA517 Grade F Mechanical Property :

Grade	Thickness	Yield	Tensile	Elongation
	mm	MinMpa	Mpa	Min%
SA517 Grade F	6-65	690	795-930	16%
	65-150	620	725-930	14%

ASME SA517 Grade F application :
With high strength, good plasticity, toughness and welding performance, mechanical module supports used in nuclear power plants.

Shanghai Royal Industry keeps more than 10,000 tons hot rolled and cold rolled SA517 Grade F steel in stock each month. We can meet our customer’s any quantity request. Based on these stock source, our advantage industry spread into steel process like : cutting ( any size and any shape ) drilling, welding, milling, machining and steel structure.

We also have a high quality logistics team who make sure the fast delivery time and shipment. Anyway, if you want to find hot rolled and cold rolled SA517 Grade F steel supplier, hot rolled and cold rolled SA517 Grade F steel manufacturer, hot rolled and cold rolled SA517 Grade F steel exporter, please contact Shanghai Royal Industry’s sales team. We will give you the hot rolled and cold rolled SA517 Grade F competitive price, hot rolled and cold rolled SA517 Grade F good quality and best service from us.
