ASME SA533 Grade C Q&T alloy steel plates for pressure vessels

Product: ASME SA533 Grade C in the standard ASME SA533/SA533M.ASME SA533 Grade C is a kind of Mn-Mo and Mn-Mo-Ni alloy steel plates material used to fabric high temperature pressure vessels. Just because ASME SA533 Grade C with the special Manganese , Molybdenum , and Manganese, Molybdenum, Nickel chemical composition, ASME SA533 has the right property to be used in high temperature pressure vessel. ASME SA533 Grade C is also a Quenching + Tempering steel material. ASME SA533 have four types A/B/C/D.

Key words:SA533 Grade C,ASME SA533 Grade C,SA533 Grade C Q&T alloy steel plates,SA533 Grade C Mn-Mo and Mn-Mo-Ni alloy steel plates,ASME SA533 Grade C Q&T alloy steel plates for pressure vessels.

ASME SA533 Grade C steel chemical composition(%) :

Composition		Grade C
C ≤ ①		0.25
Mn	Heat analyse	1.15~1.50
Mn	Product analyse	1.07~1.62
P ≤ ①		0.035
S ≤ ①		0.035
Si	Heat analyse	0.15~0.40
Si	Product analyse	0.13~0.45
Ni	Heat analyse	0.70~1.00
Ni	Product analyse	0.67~1.03
Mo	Heat analyse	0.45~0.60
Mo	Product analyse	0.41~0.64

Note : ① Be suitable for both heat analyse and product analyse.

ASME SA533 Grade C steel application :
ASME SA533 Grade C Has excellent low-temperature impact toughness and mechanical properties, is typically used for environment - 100 ~ 196 ℃ low temperature conditions .Of 9% Ni steel is widely used in cryogenic separation processing, liquefied gas storage areas, such as a large vacuum low temperature storage of liquefied natural gas (LNG).

We also have a high quality logistics team who make sure the fast delivery time and shipment. Anyway, if you want to find hot rolled and cold rolled SA533 Grade C steel supplier, hot rolled and cold rolled SA533 Grade C steel manufacturer, hot rolled and cold rolled SA533 Grade C steel exporter, please contact Shanghai Royal Industry’s sales team. We will give you the hot rolled and cold rolled SA533 Grade C competitive price, hot rolled and cold rolled SA533 Grade C good quality and best service from us.
