ASME SA-516/SA-516M steel plates for pressure vessels

ASME SA-516/SA-516M

Standard: ASME SA-516/SA-516M
Steel Grade : SA516 Gr. 55 (380), SA516 Gr. 60 (415), SA516 Gr. 65 (450) , SA516 Gr.70 (485)
Dimension range :3mm -500mm x 1000mm-4000mm x 1000mm-18000mm
MOQ: 1 PC
Delivery time : Promptly ( Stock) or 10-40 days (Production)
Stock : Available
MTC: Available
Payment Term : T/T or L/C At sight .
Latest price:

Specification :
SA516 is a kind of Carbon steel plates material used to fabric middle or low temperature pressure vessels. Obviously, SA662 is divided into four grades or levels :SA516 Gr. 55 (380), SA516 Gr. 60 (415), SA516 Gr. 65 (450) , SA516 Gr.70 (485). In the ASME SA-516/SA-516M standard, this material request for Impact test energy.

SA516 steel chemical composition :%

Compostion			SA516 Grade 55(380)	SA516 Grade 60(415)	SA516 Grade 65(450)	SA516 Grade 70(485)
C ≤ ①	≤ 12.5mm		0.18	0.21	0.24	0.27
	＞ 12.5mm ~ 50mm		0.20	0.23	0.26	0.28
	＞ 50mm ~ 100mm		0.22	0.25	0.28	0.30
	＞ 100mm ~ 200mm		0.24	0.27	0.29	0.31
	＞ 200mm		0.26	0.27	0.29	0.31
Mn	≤12.5mm②	Heat analyse	0.60~0.90	0.60~0.90	0.85~1.20	0.85~1.20
	≤12.5mm②	Product analyse	0.55~0.98	0.55~0.98	0.79~1.30	0.79~1.30
	12.5mm~50mm	Heat analyse	0.60~1.20	0.85~1.20	0.85~1.20	0.85~1.20
	12.5mm~50mm	Product analyse	0.55~1.30	0.79~1.30	0.79~1.30	0.79~1.30
P ≤ ①			0.035	0.035	0.035	0.035
S ≤ ①			0.035	0.035	0.035	0.035
Si	Heat analyse		0.15~0.40	0.15~0.40	0.15~0.40	0.15~0.40
Si	Product analyse		0.13~0.45	0.13~0.45	0.13~0.45	0.13~0.45
