ASTM A516 Grade 485 Carbon Steel Plate

Product:This specification ASTM A516 Grade 485 covers carbon steel plates intended primarily for use in welded pressure vessels where improved notch toughness is important. ASTM A516 allows for four different strength levels. The most common is Grade 70.

Key words:A516 Grade 485,ASTM A516 Grade 485, A516 Grade 485 Carbon Steel Plate,ASTM A516 Grade 485 Carbon Steel Plate,ASTM A516 Grade 485 Carbon Steel Plate for pressure vessels.

ASTM A516 Grade 485 steel chemical composition :

Composition			A516Grade70(485)
C≤①	≤12.5mm		0.27
	＞12.5mm~50mm		0.28
	＞50mm~100mm		0.30
	＞100mm~200mm		0.31
	＞200mm		0.31
Mn	≤12.5mm	Heatanalyse	0.85~1.20
		Product analyse	0.79~1.30
	12.5mm~50mm	Heatanalyse	0.85~1.20
		Product analyse	0.79~1.30
P ≤			0.035
S≤			0.035
Si	Product analyse		0.15~0.40
	Heat analyse		0.13~0.45

① means be suitable for both heat analyse and product analyse

ASTM A516 Grade 485 Mechanical Properties :

Grade	TensileKSI	YieldKSIMin	ElongationMin%
			8”	2”
70	70-90	38	17	21

Shanghai Royal Industry keeps more than 10,000 tons hot rolled and cold rolled A516 Grade 485 steel in stock each month. We can meet our customer’s any quantity request. Based on these stock source, our advantage industry spread into steel process like : cutting ( any size and any shape ) drilling, welding, milling, machining and steel structure.

We also have a high quality logistics team who make sure the fast delivery time and shipment. Anyway, if you want to find hot rolled and cold rolled A516 Grade 485 steel supplier, hot rolled and cold rolled A516 Grade 485 steel manufacturer, hot rolled and cold rolled A516 Grade 485 steel exporter, please contact Shanghai Royal Industry’s Ales team. We will give you the hot rolled and cold rolled A516 Grade 485 competitive price, hot rolled and cold rolled A516 Grade 485 good quality and best service from us.
