ASTM A516 Grade 55 Carbon Steel Plate

Product:This specification ASTM A516 Grade 55 covers carbon steel plates intended primarily for use in welded pressure vessels where improved notch toughness is important. ASTM A516 allows for four different strength levels. The most common is Grade 70.

Key words:A516 Grade 55,ASTM A516 Grade 55, A516 Grade 55 Carbon Steel Plate,ASTM A516 Grade 55 Carbon Steel Plate,ASTM A516 Grade 55 Carbon Steel Plate for pressure vessels.

ASTM A516 Grade 55 steel chemical composition :

Compostion			A516 Grade 55
C ≤ ①	≤ 12.5mm		0.18
	＞ 12.5mm ~ 50mm		0.20
	＞ 50mm ~ 100mm		0.22
	＞ 100mm ~ 200mm		0.24
	＞ 200mm		0.26
Mn	≤12.5mm	Heat analyse	0.60~0.90
		Product analyse	0.55~0.98
	12.5mm~50mm	Heat analyse	0.60~1.20
		Product analyse	0.55~1.30
P ≤ ①			0.035
S ≤ ①			0.035
Si	Heat analyse		0.15~0.40
	Product analyse		0.13~0.45

① means be suitable for both heat analyse and product analyse

ASTM A516 Grade 55 Mechanical Properties :

Grade	Tensile KSI	Yield KSI Min	Elongation Min %
			8”	2”
55	55-75	30	23	27

Shanghai Royal Industry keeps more than 10,000 tons hot rolled and cold rolled A516 Grade 55 steel in stock each month. We can meet our customer’s any quantity request. Based on these stock source, our advantage industry spread into steel process like : cutting ( any size and any shape ) drilling, welding, milling, machining and steel structure.

We also have a high quality logistics team who make sure the fast delivery time and shipment. Anyway, if you want to find hot rolled and cold rolled A516 Grade 55 steel supplier, hot rolled and cold rolled A516 Grade 55 steel manufacturer, hot rolled and cold rolled A516 Grade 55 steel exporter, please contact Shanghai Royal Industry’s Ales team. We will give you the hot rolled and cold rolled A516 Grade 55 competitive price, hot rolled and cold rolled A516 Grade 55 good quality and best service from us.
